MGL Accessories
- You will find on this page miscellaneous accessories supplied by DELTA OMEGA.
- Subscribe to our
MGL newsletter
- Faire une demande de
Catalogue/Tarif
|
|
Avioguard
- AvioGuard Isolated DC/DC converter for avionics applications.
- Wide input range (9-36V) solution provides clean 13.8V DC for quality power supply to sensitive avionics in the cockpit
- High levels of fault protection and complete galvanic input to output isolation plus simple avionics battery backup solutions complete this useful device
- DC input voltage range: 9V to 36V
- DC output voltage: 12V, 12.6V, 13.2V, 13.8V (model dependent, 13.8V is standard). Note: 13.8V model outputs about 13.6V (for backup battery use).
- DC output current: 0-6A continuous. 8A peak (short duration). 10A
maximum (over current protection limit)
- Line regulation: 0.05%
- Load regulation: 0.05%
- No load DC input current: 0.2A (12V DC input)
- Power conversion efficiency: Up to 90%
- Start up minimum voltage: 9.0V
- Undervoltage shutdown: 8.0V
- Input overvoltage shutdown: 37.0V (input protected in addition by 43V transorbs)
- Output short circuit current: 250mA (input current with output shorted)
- Output reverse current: <1mA (No input voltage, 12V applied on output)
- Isolation voltage: 750 volts minimum (to housing, input to output
- Weight: 320g
- Ref : MG_AvioG
- Ask for a Catalog/Price list
Top of page
|
| USB Programming cable "Vega" | |
|
|
MGL Avionics Vega USBPC USB programming Cable
- This cable contains a USB to RS-232 converter and allows the connection of a Vega instrument to a PC for firmware updates.
- Requires a DC supply (8 to 30V, approx 100mA @ 12V) to power the Vega instrument.
- Poids : approx. 100g
- Ref : MG_Veg_USBPC
-
Ask for a Catalog/Price list
Top of page
|
| RS232 Programming cable "Vega" | |
|
|
MGL Avionics Vega RS232 programming Cable
- This cable allows the connection of a Vega instrument to a PC for firmware updates of the instrument.
- Requires a DC supply (8 to 30V, approx 100mA @ 12V) to power the Vega instrument.
- Poids : approx. 35g
- Ref : MG_Veg_RS232
-
Ask for a Catalog/Price list
Top of page
|
| "Infinity" programming adapter | |
|
|
Infinity Airtalk Adapter
- AIRTALK programming adaptor
- Allow connection of an "Infinity" instrument to an "Airtalk" link, for firmware updates
- The "Airtalk" to PC connction can be made with an Airtalk-Serial cable.
- Requires DC supply 8 to 28V.
- Réf : MG_Inf_Adapt
- Ask for a Catalog/Price list
Top of page
|
| BlueTooth connection for AIRTALK | |
|
| Bluetooth connection for GPS/autopilot data | |
|
|
- This option allows broadcasting the GPS and AP data available at the back of ENIGMA or ODYSSEY through a wireless Bluetooth connection, for usage on a BlueTooth equipped PocketPC or computer.
- Typical use: A BlueTooth equiped PocketPC runs a navigation software application (
NAVI,
PocketFMS,
Winpilot,
, etc..) and use GPS and GOTO data from ENIGMA or ODYSSEY.
- Speed 4800 Bauds.
- Speed 4800 bauds.
- Typical current 45mA.
- Typique distance 10m.
- Operating temperature -30°C ~ 90°C.
- Weight 40g approximatly.
- Réf : MG_PA_BT
- Ask for a Catalog/Price list
Top of page
|
|
SmartSingles Cable PC
- This cable is used for the direct connection between your computer (or notebook computer) to your Stratomaster Flight, Stratomaster Extreme or Stratomaster Ultra instrument.
- Converts "Airtalk" signal into PC compatible signals.
- Note: This cable is included in the flight log download key package.
- Ref: MG_Airtalk_CA
- Ask for a Catalog/Price list
Top of page
|
|
SmartSingles Clé Vidage
- 24 x 22 x 65 mm.
- This unit is used to transfer your instruments flight log details into our Flight log program.
- It can store the full flight log up to a maximum of 240 flights.
- All you have to do is every now and then connect the key to your instrument to update any new flights you have done since the last time the key was connected.
- Once the data has been downloaded into the key it can then be connected and transferred to the Flight log program running on the PC.
- Airtalk to PC cable (Ref : MG_Airtalk_CA) included.
- Flight log software not included - It can be downloaded freely
here.
- Download the manual Download_key.pdf
- Ref: MG_Keyring
- Ask for a Catalog/Price list
Top of page
|
|
Converter CNV-ALT
- Serial (Airtalk ou RS232) altitude to parallel Gillham code.
- Converts the serial altitude data from the Infinity ASX-2 / ALT-2 / XTreme EFIS to Gillham codes suitable for connection to a mode-c transponder.
- Power supply 8 to 28V DC, current drain approx. 15mA @ 13.8V (all outputs OFF)
- Download the manual cnv-alt.pdf
- Ref : MG_CNV_Alt
Top of page
|
|
Converter CNV-ALT2
- This device converts the serial altitude data from the Infinity ALT-2 / XTreme EFIS to Gillham codes suitable for connection to a mode-c transponder.
- Power supply 8 to 28V DC, current drain 20mA @ 13.4V
- Download the manual cnv-alt2_en.pdf
- Réf : MG_CNV_alt2
- Ask for a Catalog/Price list
Top of page
|
|
Capacitor
- This 10 000uF electrolytic capacitor is an inexpensive and useful addition to your aircrafts power supply.
- It can significantly reduce noise signals on your power supply that may be affecting your VHF radio such as ignition noise or rectifier/regulator noise artifacts.
- The capacitor must be installed as close as possible to the noise source with very short leads for maximum effect.
- Ref: MG_10KuFCap
- Ask for a Catalog/Price list
Top of page
|
| EMI Interference Suppressor | |
|
|
TransZorb
- This device is used for the effective overvoltage protection of sensitive electronic equipment on your aircraft.
- Voltages of several thousand volts can be measured in your aircraft when operating devices such as electrical motors, starter motors or solenoids. The surge protector clamps these voltages to an acceptable level suitable for electronic equipment.
- Not fitting such a device has been responsible for much damage to radios and other electronic equipment on aircraft.
- Download the manual tz_en.pdf
- Ref: MG_33VTR
- Ask for a Catalog/Price list
Top of page
|
|
Pilot Light with Soinder
- Combine a pulsing audible signal (80d @1m) with a visual indication
- Pulsing indicator is perfect for use in alarm circuits
- Quick and easy installation with a back of panel lock nut and captive screw terminals
- 12V AC/DC 20mA
- Ref : MG_VBuz
- Ask for a Catalog/Price list
Top of page
|
| Backup Batteries for ENIGMA | |
|
|
Backup Battery for EFIS
- 12V lead acid sealed battery
- Weight 360g, Dim 96 x 25 x 62 mm
- Connector AMP Housing 1-480318-0 & 8116-1
- 0.8Ah (20h) 0.48Ah (1h)
- As ENIGMA backup about 40mn @ full brightness (700mA)& 72mn @ half brightness (400mA)
- Ref: MG_BAT_12V0.8A
- Ask for a Catalog/Price list
- 12V lead acid sealed battery
- Weight 600g, Dim 97 x 43 x 52mm
- 1.4Ah (20h) 0.85Ah (1h)
- As ENIGMA backup about 77mn @ full brightness (700mA)& 135mn @ half brightness (400mA)
- Ref: MG_BAT_12V1.2A
- Ask for a Catalog/Price list
Top of page
|
| Stratomaster Flight Log Program | |
|
|
Stratomaster Flight Log
- The Stratomaster Flight Log program can be used for the extraction and viewing of all your flight data from one of the following instruments:
Stratomaster Flight
Stratomaster Extreme
Stratomaster Ultra (all types).
- Simply connect it from your computer to the instrument using our Airtalk to PC cable or alternatively data can be downloaded to the PC using the Log download device.
- From version 1.5 onwards, the flightlog program can also use the new USB to airtalk interface.
- Easy maintenance of your flight log
- The flight log can be printed
- Flight time calculator can add the times between two given dates
- Windows 95, 98, ME, XP, NT and 2000 compatible
- Download the program
setupsmlog.exe
Top of page
|
|
HXL Panel Designer
- This free PC software package can be used to easyly customize your Ultra in the comfort of your armchair, and then later at a click of a button, download the configuration you have just created into the Ultra.
- This program allows you to simulate the actual Ultra instrument with all its functions. In addition you can use it to design your own screen layouts and configure your instrument in detail. When you are ready, you can simply download your design to the real instrument.
- You can also upload designs from your instrument to your PC and store these for use with other Ultras, you can create a whole personalized library of screen layouts and instrument setups.
- This program is also used to update your Ultra to the latest firmware release so you can be sure you allways have the latest software and features installed.
- Requires PC, Windows 95,98,ME,NT,2000,XP. For simulation, 2.0Ghz PC minimum required
- Download right here for free: UltraHXLSetup.zip
